(0 đánh giá) Kinh Doanh 1: Admin:0911.599.997 Hỗ Trợ Bảo Hành :0911.599.997 Dòng sản phẩm bo mạch chủ PRO series đến từ MSI giúp người dùng làm việc thông minh hơn thông qua những trải nghiệm sáng tạo và hiệu quả. Được lắp ráp với những tính năng ổn định và chất lượng cao, bo mạch chủ PRO series đem đến không chỉ quy trình công việc chuyên nghiệp tối ưu, mà còn ít lỗi hơn và bền bỉ hơn.
| Mainboard (Bo mạch chủ) | MSI |
| Hãng sản xuất | MSI |
| PROCESSOR | Supports 12th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors 1 - - Processor socket LGA1700 - - Please go to www.msi.com to get the newest support status as new processors are released. |
| CHIPSET | Intel® H610 Chipset |
| RAM | 2x DDR4 memory slots, support up to 64GB 1 - - Supports 1R 2133/ 2666/ 3200 MHz (by JEDEC & POR) - - Supports Dual-Channel mode - - Supports non-ECC, un-buffered memory - - Please refer to www.msi.com for more information on compatible memory. |
| EXPANSION SLOT | 1x PCIe x16 slot (From CPU) - - Supports up to PCIe 4.0 x16 - - 1x PCIe x1 slot (From H610 chipset) - - Supports PCIe 3.0 x1 |
| ONBOARD GRAPHICS | 1x HDMI 1.4 with HDR port, supporting a maximum resolution of 4K 30Hz 1 / 2 - - 1x VGA port, supporting a maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz 1 / 2 - - Available only on processors featuring integrated graphics. - - Graphics specifications may vary depending on the CPU installed. |
| SATA PORTS | 4x SATA 6Gb/s ports (From H610 chipset) |
| M.2 SSD SLOT | 1x M.2 slot (Key M) (from CPU) - - Supports up to PCIe 3.0 x4 - - Supports 2242/ 2260/ 2280 storage devices |
| AUDIO | Realtek® ALC897 Codec - - 7.1-Channel High Definition Audio |
| LAN | 1x Realtek® RTL8111H 1Gbps LAN controller |
| POWER CONNECTORS | 1x 24-pin ATX main power connector - 1x 8-pin +12V power connector |
| INTERNAL USB CONNECTORS | 1x USB 3.2 Gen 1 5Gbps connector (From H610 chipset) - - Supports additional 2 USB 3.2 Gen 1 5Gbps ports - - 2x USB 2.0 Type-A connectors (From Hub-GL850G) - - Supports additional 4 USB 2.0 ports |
| FAN CONNECTORS | 1x 4-pin CPU fan connector - - 2x 4-pin system fan connectors |
| SYSTEM CONNECTORS | 1x Front panel audio connector - - 2x System panel connectors - - 1x Chassis Intrusion connector - - 1x TPM module connector - - 1x Serial port connector |
| JUMPERS | 1x Clear CMOS jumper |
| LED FEATURES | 1x 4-pin RGB LED connector - - 4x EZ Debug LED |
| BACK PANEL PORTS | HDMI - - VGA - - Keyboard / Mouse - - USB 3.2 Gen 1 5Gbps Type-A - - LAN port - - Audio connector - - USB 2.0 |
| DIMENSIONS | M-ATX Form Factor - - 9.3 in. x 7.9 in. (23.6 cm x 20 cm) |
